Automatic Laminating Machine – 89*100 cm

YFM-920A / YFM-1100A is a fully automatic laminating machine engineered for high-speed, high-volume operations in professional printing environments. Offering a maximum laminating width of 1050mm and speeds of up to 80 meters per minute, it guarantees flawless finishes even in the most demanding runs.

With support for paper thickness from 105 to 500 gsm and a maximum film roll diameter of 350mm, this machine handles a wide range of applications. Its 33-35 kW power system ensures consistent performance, while the heavy-duty build (up to 4500 kg) stands up to years of continuous use.

Technical Specifications:

• Max Laminating Width: 889mm * 1050mm
• Max Sheet Size (W*L): 889*1000mm – 1050*1050mm
• Min Sheet Size (W*L): 340*340mm
• Paper Thickness: 105-500 gsm
• Max Film Roll Diameter: 350mm
• Power Required: 33 kW / 35 kW (380V AC 3 50/60Hz)
• Laminating Speed: 5-80 m/min
• Dimension: 8800*1650*1980mm – 8800*1830*1980mm
• Machine Weight: 4000-4500 kg
