Automatic Rigid Box Forming Machine – 500 * 400 mm

Automatic Rigid Box Forming Machine by New Star Machinery is engineered to deliver high-speed, precise, and automated production of rigid boxes. Ideal for industries such as fashion, jewelry, electronics, and premium packaging, this machine ensures consistent quality and efficiency.

Key Features:

• High-Speed Production: Capable of producing 18-28 boxes per minute.
• Precision Positioning: Achieves accurate positioning with a tolerance of 0.05mm.
• Versatile Box Sizes: Accommodates a range of box sizes to meet diverse packaging needs.
• Advanced Control Systems: Equipped with servo motors and PLC control for reliable and efficient operation.
• User-Friendly Interface: Features an intuitive control panel for easy operation and adjustments.
  Machine Specifications:

  Parameter	Specification
  Max Box Size	500 * 400 mm
  Min Box Size	90 * 70 mm
  Box Molding Height	10-120 mm
  Speed	18-28 pcs/min
  Positioning Accuracy	0.05 mm
  Glue Barrel Capacity	20 L
  Conveyor Belt Height	900 mm / 1100 mm
  Max Height of Paper Stack	280 mm / 580 mm
  Air Pressure	0.6-0.8 MPa
  Power Supply	380V / 50Hz
  Total Power	14 kW
  Machine Weight	Approx. 7000 kg
