Heidelberg CD 102-5+LX – 72 × 102 cm – 2004

The Heidelberg CD 102-5+LX (2004) is a versatile and highly productive sheetfed offset press engineered for demanding multi-color printing applications with inline coating capability. Built on Heidelberg’s proven CD platform, the machine provides reliable sheet handling, precise ink control, and consistent print quality across long production runs.

This post-Drupa configuration is equipped with the CP2000 control console and Master Level software license, allowing centralized monitoring and control of all press parameters. Integration features such as Instant Gate and PresetLink enable seamless communication between prepress workflows and the press control system, improving job preparation and production efficiency.

The press features advanced ink and dampening management through the Technotrans CombiStar system and Alcolor VARIO dampening with speed compensation, ensuring a stable ink-water balance. The DryStar Advanced and DryStar 3000 drying systems combine infrared and hot air technologies to reduce waiting times and ensure efficient drying when working with coatings and demanding print jobs.

Additional automation features include Preset Plus feeder and delivery systems, semi-automatic Autoplate plate change, automatic format presetting, and Venturi air transfer technology for smooth sheet transport. The coating unit with an anilox roller allows high-quality inline varnishing, while the extended delivery (X2) provides improved drying and sheet handling.

Supporting systems such as CleanStar powder extraction, AirStar centralized air supply, ScrollStar Atlas Copco compressor, and HydroStar dampening optimization further enhance operational reliability. These features make the Heidelberg CD 102-5+LX a powerful solution for professional commercial printing and coated print production.

Key Features

5-color sheetfed offset printing configuration
Inline coating unit with anilox roller
CP2000 centralized press control console
Post-Drupa configuration with advanced automation
DryStar Advanced and DryStar 3000 drying systems
Preset Plus feeder and delivery systems
Autoplate semi-automatic plate change
Extended delivery system (X2 – 160 cm)
Integration with prepress workflows via Instant Gate and PresetLink

Technical Specifications

Model: CD 102-5+LX
Manufacturer: Heidelberg
Year of Manufacture: 2004
Serial Number: 546395
Impressions: approx. 243 million

Post-Drupa configuration
CP2000 console for monitoring and control of the machine
Master Level software license
DryStar Advanced drying system
Instant Gate data transfer from Prinect Prepress Interface to Print Center
PresetLink connection between Prepress Interface and CP2000
Preset Plus feeder with suction tape feeder
Ink temperature control
Alcolor VARIO dampening system with speed compensation
Technotrans Combi refrigeration unit
Automatic washing of blankets, rollers and impression cylinders
Autoplate semi-automatic plate change
Preset automatic paper size setting
Venturi air transfer system
Varnish unit with anilox roller
Preset Plus delivery system
X2 extended delivery (160 cm)
PowderStar Grafix Exatronic Plus powder spray
DryStar 3000 IR + hot air combination dryers
CleanStar powder extrusion system
AirStar centralized soundproof cabin for air pumps
ScrollStar Atlas Copco compressor
HydroStar dampening optimization system
CombiStar Technotrans CAN ink temperature control with AlcolSmart IPA dosing
Water-cooled system (chiller not included)

Note: Techkon SpectroDrive is not included but can be purchased separately.

Applications

Commercial printing
Packaging printing
Catalogs and brochures
Marketing and promotional materials
High-quality coated print production
