Screen PT-R4300 E (CTP) – 830 * 660 mm – 2008

Screen PT‑R4300E is a thermal Computer-to-Plate (CTP) plate setter that combines high precision, flexibility, and efficiency in prepress production. Designed for 4-up plate workflows, it supports a wide range of plate formats with stable, high-resolution output.

Technical Specifications:

• Model: PT‑R4300E (Thermal CTP)
• Year: 2008
• Maximum Plate Size: 830 * 660 mm (32.6 * 25.9)
• Minimum Plate Size: 324 * 370 mm (12.8 * 14.6); 304 * 370 mm
• Resolution: 2,400 / 2,438 / 2,540 dpi
• Throughput: Approx. 11 plates/hour at 2,400 dpi
• Light Source: 16-channel infrared laser diodes
• Loading System: Manual loader or optional SA-L4300 autoloader (50-plate capacity)
• Plate Thickness: 0.15 – 0.30 mm
• Design: External drum with plate stacking and optional inline punch and gumming units
• Dimensions (L × W × H): 1,750 * 1,030 * 1,178 mm
